Security Indicator Light Assembly: Components: Illustration

Fig 1: Identifying Security Indicator Light Assembly Replacement Components With Torque Specifications (1 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 1: Identifying Security Indicator Light Assembly Replacement Components (2 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
