Engine Control System (2GR-FSE) (Service Information)
›
Heated Oxygen Sensor
›
Components
›
Illustration
Heated Oxygen Sensor: Components: Illustration
Fig 1: Identifying Heated Oxygen Sensor Replacement Components With Torque Specifications
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
