Components [10/2015 - ]: Illustration

Fig 1: ECM Replacement Components With Torque Specifications

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Callout	Description	Callout	Description
*1	COOL AIR INTAKE DUCT SEAL	*2	ECM
*3	ECM BRACKET	*4	ENGINE ROOM ECU COVER
*5	NO. 2 ECM BRACKET	*6	ENGINE ROOM MAIN WIRE
*7	ENGINE WIRE	*8	ENGINE ROOM SIDE COVER
	N*m (kgf*cm, ft.*lbf): Specified torque	-	-
