Components [06/2018 - ]

Fig 1: Crankshaft Position Sensor Replacement Components With Torque Specifications

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*1	COOL AIR INTAKE DUCT SEAL	*2	CRANKSHAFT POSITION SENSOR
*3	INLET AIR CLEANER ASSEMBLY	-	-
	N.m (kgf/cm, ft.lbf): Specified torque	-	-
