Item 1: Transmission Assembly Installation Note

    NOTE: Align the flexplate-to-converter marks made during the removal procedure.
    Fig 1: Aligning Flexplate-To-Converter Marks Made During
    G01285175Courtesy of FORD MOTOR CO.
  1. While raising and positioning the transmission to the engine, install the wire harness to the top of the transmission.
