Transfer Case

To install, reverse the removal procedure.
- Install a new transfer case-to-transmission gasket.
- Fill the transfer case. For additional information, refer to TRANSFER CASE DRAINING AND FILLING when refilling the transfer case. Refer to SPECIFICATIONS for the correct type and quantity of fluid.
- Tighten the transfer case-to-transmission bolts evenly in a star pattern.

  Fig 1: Tightening Transfer Case-To-Transmission Bolts In Star Pattern
  Courtesy of FORD MOTOR CO.
