Special Tool(s)

SPECIAL TOOL(S) CHART

Tool No. Illustration Description
ST1277-A
G03862235Courtesy of FORD MOTOR CO.
 Commercially Available Hydraulic Lash Adjuster Leakdown Tester
-
ST1299-A
G03862236Courtesy of FORD MOTOR CO.
 Quick Disconnect Compression Tester 134-R0212 or equivalent
ST1272-A
G03862237Courtesy of FORD MOTOR CO.
 Dial Indicator Gauge Adapter 303-007 (TOOL-6565-AB) or equivalent
ST1214-A
G03862238Courtesy of FORD MOTOR CO.
 Dial Indicator Gauge with Holding Fixture 100-002 (TOOL-4201-C) or equivalent
ST1298-A
G03862239Courtesy of FORD MOTOR CO.
 Engine Cylinder Leak Detection/Air Pressurization Kit 014-00708 or equivalent
ST1296-A
G03862240Courtesy of FORD MOTOR CO.
 Oil Pressure Gauge 303-088 (T73L-6600-A)
ST1300-A
G03862241Courtesy of FORD MOTOR CO.
 UV Leak Detector Kit 164-R0756 or equivalent
ST1297-A
G03862242Courtesy of FORD MOTOR CO.
 Vacuum/Pressure Tester 164-R0253 or equivalent
