| A/C Compressor-To-Bracket Bolt |
17-26 (23-35) |
| Camshaft Sprocket Bolt |
36-45 (49-61) |
| Connecting Rod Cap Nut |
35-38 (47-52) |
| Crankshaft Pulley Attaching Bolts |
9-13 (12-18) |
| Crankshaft/Timing Belt Sprocket Bolt |
80-87 (109-118) |
| Cylinder Head Bolt |
| Step 1 |
35-40 (47-54) |
| Step 2 (Final) |
56-60 (76-81) |
| Engine Hanger Bolt |
| SOHC (Front) |
27-46 (37-62) |
| SOHC (Rear) |
14-19 (19-26) |
| Engine/Transaxle Mount-To-Crossmember Mounting Nut |
| Large |
42-66 (64-90) |
| Small |
27-38 (37-52) |
| Exhaust Header Pipe-To-Exhaust Manifold Bolt |
23-34 (31-46) |
| Exhaust Manifold-To-Head Bolt |
12-17 (16-23) |
| Flywheel Bolt |
71-76 (96-103) |
| Intake Manifold Support Brace |
14-19 (19-26) |
| Intake Manifold-To-Upper Manifold Bolt & Nut |
14-19 (19-26) |
| Main Bearing Cap Bolt |
| Step 1 |
22-27 (30-37) |
| Step 2 (Final) |
40-43 (54-58) |
| Main Bearing Support Plate-To- Main Bearing Cap Bolt |
10-13 (14-18) |
| Oil Pan Support-To-Transaxle |
47-66 (64-89) |
| Oil Pump-To-Block Bolt |
14-19 (19-26) |
| PPF/Differential Spacer Mounting Bolt |
27-38 (37-52) |
| PPF-To-Differential Long Mounting Bolt |
77-91 (104-123) |
| PPF-To-Transmission Side Mounting Bolt |
77-91 (104-123) |
| PPF/Transmission Rear Bracket Mounting Bolt |
27-40 (37-54) |
| P/S Pump-To-Bracket Bolt |
27-38 (37-52) |
| Spark Plug |
11-17 (15-23) |
| Rocker Arm Shaft Bolt (SOHC) |
16-21 (22-29) |
| Throttle Body Nut |
14-19 (19-26) |
| Timing Belt Pulley Bolt |
80-87 (109-118) |
| Timing Belt Tensioner Bolt |
14-19 (19-26) |
| Water Pump Bolt |
14-19 (19-26) |
| INCH Lbs. (N.m) |
| Air Valve |
40-58 (5-7) |
| Camshaft Thrust Plate Bolt |
69-95 (8-11) |
| Camshaft/Rocker Cover Bolt |
| SOHC (Top) |
43-78 (5-9) |
| SOHC (Timing Belt Cover-To-Camshaft Cover) |
69-95 (8-11) |
| Crankshaft Pulley Bolts |
109-152 (12-17) |
| Oil Jet |
104-156 (12-18) |
| Oil Pan Bolt |
69-95 (8-11) |
| Oil Strainer Bolt |
69-95 (8-11) |
