Testing Preparation Procedure
- The following 4 steps apply to all trouble shooting operations under this heading.
- Check engine coolant, oil and transmission fluid levels and adjust as necessary. Warm engine and transmission to operating temperatures.
- Set parking brake and chock wheels front and rear for stall and line pressure test.
- Drive vehicle for road test, line pressure cut-back point and governor pressures.
- If transmission problems occur on initial road test, check adjustments. See appropriate article in TRANSMISSION SERVICING section.
Courtesy of MAZDA MOTORS CORP.
