Code 4: Distributor - SGT Signal

Fig 1: Trouble Code No. 4 Distributor - SGT Signal

G95J31962

Fig 2: Trouble Code No. 4 Distributor (Camshaft Position Sensor) Circuit Diagram

G95A31963
