OEM Wiring Diagram
›
Engine-Related System
›
Key Interlock System/Shift-Lock System
Key Interlock System/Shift-Lock System
Fig 1: Key Interlock System/Shift-Lock System Wiring Diagram (H-2; 1 Of 2)
Courtesy of MAZDA MOTORS CORP.
Fig 2: Key Interlock System/Shift-Lock System Wiring Diagram (H-2; 2 Of 2)
Courtesy of MAZDA MOTORS CORP.
Courtesy of MAZDA MOTORS CORP.
Courtesy of MAZDA MOTORS CORP.
