Shift Lock Actuator Removal/Installation

Remove the steering column assembly; see STEERING COLUMN REMOVAL/INSTALLATION .
Remove the insert plate and the shift lock actuator.
1. Remove the bolts.
2. Remove the insert plate and the shift lock actuator.
Fig 1: Removing Insert Plate And Shift Lock Actuator
Courtesy of MAZDA MOTORS CORP.
NOTE:
- The shift lock actuator clip is an assembly aid for the assembly plant and does not need to be replaced.
Remove the insert plate from the shift lock actuator.
- Remove and discard the shift lock actuator clip.
Fig 2: Removing And Discarding Shift Lock Actuator Clip
Courtesy of MAZDA MOTORS CORP.
Install in reverse order of removal.
