Vehicle Harness-Side Connector

NOTE: Part names are shown only when there are multiple connector drawings.
• The viewing direction of vehicle harness-side connectors is from the harness side.

Fig 1: Viewing Direction Of Vehicle Harness-Side Connector

Courtesy of MAZDA MOTORS CORP.
