Rear Abs Wheel-Speed Sensor Removal/Installation
›
Notes
Rear Abs Wheel-Speed Sensor Removal/Installation: Notes
Remove the under cover (rear).
Remove in the order indicated in the table.
Install in the reverse order of removal.
Fig 1: Removing Under Cover (Rear) & Torque Specification
Courtesy of MAZDA MOTORS CORP.
