Home › Mazda › 2006 › B3000 Base, Automatic › Repair and Diagnosis › Steering › Power Steering › Power Steering System › Steering Column MULTIFUNCTION Switch › Notes

Steering Column MULTIFUNCTION Switch: Notes

Fig 1: Exploded View - Steering Column Multifunction Switch With Torque Specifications
G04309703Courtesy of MAZDA MOTORS CORP.
