Battery Removal/Installation [L3]: Notes
- Remove in the order indicated in the table.
- Install in the reverse order of removal.BATTERY COMPONENT CHART
1 Battery cover
(See BATTERY COVER INSTALLATION NOTE ).2 Negative battery cable 3 Positive battery cable 4 Battery duct
(See BATTERY DUCT INSTALLATION NOTE ).5 Battery box
(See BATTERY BOX INSTALLATION NOTE ).6 Battery clamp
(See BATTERY CLAMP INSTALLATION NOTE ).7 Battery 8 PCM cover
(See PCM COVER INSTALLATION NOTE ).9 Connectors 10 Battery tray and PCM component
