No. 2 All Keyless Entry System Functions Inoperative [Keyless Entry System]: Notes
- When performing an asterisked (*) troubleshooting inspection, slightly shake the wiring harness and connectors while performing the inspection to discover whether poor contact points are the cause of any intermittent malfunctions. If there is a problem, verify that the connectors, terminals and wiring harnesses are connected correctly and undamaged.
DESCRIPTION AND POSSIBLE CAUSE
| 2 |
All keyless entry system functions inoperative |
| DESCRIPTION |
- Malfunction in BCM power supply circuit, door latch switch circuit, BCM ground circuit, or keyless receiver.
|
| POSSIBLE CAUSE |
- Malfunction in IG1 or power supply signal circuit of BCM
- BCM power supply fuse malfunction
- Malfunction in wiring harness between BCM power supply fuses and BCM
- Malfunction in door open/closed signal circuit of BCM
- Door latch switch system malfunction
- BCM malfunction
- Malfunction in wiring harness between BCM and door latch switch
- Malfunction in BCM GND signal circuit
- Malfunction in wiring harness between BCM and ground
- Malfunction in keyless receiver
- Keyless receiver malfunction
- Malfunction in wiring harness between keyless receiver and BCM
|
