Liftgate Handle, Lock And Latch - Exploded View

Fig 1: Exploded View Of Liftgate Handle, Lock And Latch Components With Torque Specifications
G07436676Courtesy of MAZDA MOTORS CORP.
  1. For additional information, see the appropriate procedures in this service information.
