Liftgate Recess Removal/Installation

Insert a fastener remover in the position indicated by the arrow in the figure and detach tabs A.

Fig 1: Identifying Liftgate Recess Tabs A
Remove the liftgate recess in the direction of the arrow shown in the figure detaching the tabs B.

Fig 2: Removing Liftgate Recess With Tabs B
Install in the reverse order of removal.
