Section 564 (Entertainment System)
›
Audio Control Switch Inspection
›
Without Bluetooth System
Without Bluetooth System
WARNING:
This page is about a different car, the 2009 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Audio Control Switch Without Bluetooth System
Courtesy of MAZDA MOTORS CORP.
If the resistance and continuity are not as indicated in the tables, replace the audio control switch.
Fig 2: Bluetooth Position Terminal Resistance Chart
Courtesy of MAZDA MOTORS CORP.
