Clip Replacement Note

If the clip has been damaged, perform the following procedure.
1. Remove the rubber boot.

  Fig 1: Removing Rubber Boot
  Courtesy of MAZDA MOTORS CORP.
2. Remove the screw.

  Fig 2: Removing Power Outer Mirror Screw
  Courtesy of MAZDA MOTORS CORP.
3. Remove the clip.
4. Install in the reverse order of removal.
