Brake Pipe Installation Note

1. Align the marks made before removal and install the brake pipe to the DSC HU/CM and brake pipe joint referring to the figure below.

Fig 1: Master Cylinders And Alignment Marks

Courtesy of MAZDA MOTORS CORP.
