Electrical System: Fuse: Other

WARNING: This page is about a different car, the 2016 Mazda CX-3. However, it is still accessible from the selected car via links, so may be relevant.

When it is necessary to show the terminal side of the vehicle wiring harness-side connectors, such as the following connectors, the viewing orientation is from the terminal side.

Fig 1: Identifying Vehicle Harness-Side Connector (Terminal Side)
Courtesy of MAZDA MOTORS CORP.
- Main fuse block and the main fuse block relays
- Data link connector
- Check connector
- Relay box
