Troubleshooting Procedure

WARNING: This page is about a different car, the 2017 Mazda CX-9. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Front Body Control Module (FBCM) Troubleshooting Flow Chart

Courtesy of MAZDA MOTORS CORP.
