Using Hand Held Tester (HHT)

Turn ignition off. Connect HHT to 38-pin diagnostic connector located in engine compartment. See Fig 1. Turn ignition on. Follow manufacturer's instructions for reading fault codes.

Fig 1: Locating 38-Pin Diagnostic Connector

Courtesy of MERCEDES-BENZ OF NORTH AMERICA
