DATC Module C228a

WARNING: This page is about a different car, the 2003 Mercury Mountaineer and 2003 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying DATC Module C228a Terminal View (1 Of 2)

Courtesy of FORD MOTOR CO.

Fig 2: Identifying DATC Module C228a Terminal View (2 Of 2)

Courtesy of FORD MOTOR CO.
