Function Selector Switch C294b - Manual Climate Control
WARNING: This page is about a different car, the 2003 Mercury Mountaineer and 2003 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Function Selector Switch C294b - Manual Climate Control (1 Of 2)
Courtesy of FORD MOTOR CO.
Fig 2: Identifying Function Selector Switch C294b - Manual Climate Control (2 Of 2)
