Description And Operation
›
Vehicle Certification (VC) Label Reference
›
Axle Ratio Code
Axle Ratio Code
Fig 1: Identifying Axle Ratio Code
Courtesy of FORD MOTOR CO.
The axle ratios are:
1 - 2.73 conventional (non-limited slip)
4 - 2.73 conventional (non-limited slip)
5 - 3.55 conventional (limited slip)
C - 3.27 (limited slip)
F - 3.55 (locker)
