Heated Seat Switch - Rear: Notes

Fig 1: Heated Seat Switch - Rear

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	-	Front floor console
2	045A36	Front floor console rear panel
3	-	Power point electrical connector (part of 14B079)
4	-	LH rear heated seat switch electrical connector (part of 14B079)
5	-	LH rear heated seat switch
6	-	RH rear heated seat switch electrical connector (part of 14B079)
7	-	RH rear heated seat switch
