In-Vehicle Temperature Sensor: Notes

WARNING: This page is about a different car, the 2008 Mercury Sable, 2008 Ford Taurus X, and 2008 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: In-Vehicle Temperature Sensor - Taurus/Sable

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	19C734	In-vehicle temperature sensor

Fig 2: In-Vehicle Temperature Sensor - Taurus X

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	W707628	Lower steering column cover screw (3 required)
2	7404459	Lower steering column cover
3	W707281	Lower steering column shroud screw (3 required)
4	-	Lower steering column shroud
5	19C734	In-vehicle temperature sensor
6	-	In-vehicle temperature sensor electrical connector (part of 14401)
