33... Rear axle layout

WARNING: This page is about a different car, the 2011 BMW M3, 2010 BMW M3, 2009 BMW M3, and 2008 BMW M3. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Rear Axle Components

Courtesy of BMW OF NORTH AMERICA, INC.

Safety precautions & general information

Final drive/output shafts
Rear axle carrier
Compression strut/tension strut
Arm
Wheel bearing/drive flange
Shock absorber
Stabilizer
Coil spring
Stabilizer link
Wheel carrier
Adjustment work
Troubleshooting (shock absorber/rear axle)
Testing
