41 00... Overview Of Adhesive Cartridge Guns

WARNING: This page is about a different car, the 2013 BMW 550i GT, 2012 BMW 550i GT, 2011 BMW 550i GT, and 2010 BMW 550i GT. However, it is still accessible from the selected car via links, so may be relevant.

Adhesive gun 83 19 2 149 522

Obtainable via Electronic Parts Catalogue.

Usable for adhesives K4, K5a.

Including insert 1:1 and 2:1.

Fig 1: Identifying Adhesive Gun (83 19 2 149 522)

Courtesy of BMW OF NORTH AMERICA, INC.

Adhesive gun 81 49 0 443 166

Usable for adhesive K3.

Fig 2: Identifying Adhesive Gun (81 49 0 443 166)

Courtesy of BMW OF NORTH AMERICA, INC.

Adhesive cartridge gun 81 49 2 213 059

Useable for adhesives K1, K2, K5b, sealant D1, window glass adhesive and all 310 ml Euro cartridges.

Fig 3: Identifying Adhesive Gun (81 49 2 213 059)

Courtesy of BMW OF NORTH AMERICA, INC.

Adhesive cartridge gun 83 30 0 494 836

Usable for structural foam HS2.

NOTE: Special tool number 41 3 010

Fig 4: Identifying Adhesive Gun (83 30 0 494 836)

Courtesy of BMW OF NORTH AMERICA, INC.
