Description & Operation: Notes

The automatic brake control system is designed to provide efficient braking for quick stops on wet or icy road surfaces, and reduce the chances of vehicle skidding. The anti-lock control system is designed for the rear wheels only. If the front wheels become locked, the automatic brake control system will not work.

Fig 1: Rear Brake Lock-Up Control Component Locations
G50114
