Control Units
CONTROL UNITS LOCATION
| Component | Location | |
|---|---|---|
| ABS Control Unit | On left side of luggage compartment. See Figure . | |
| A/C Belt Lock Controller | Mounted on evaporator case. See Figure . | |
| A/C Control Unit | Behind center of dash, forward of center console. | |
| Active-ECS Control Unit | On right side of luggage compartment. | |
| Antenna Motor Control Unit | On left side of luggage compartment. | |
| A/T Control Unit | Behind center console. | |
| Auto. Light Shutoff Control Unit | Under center of dash, near ETACS control unit. See Figure . | |
| Cruise Control Unit | Under center of dash, behind center console. | |
| Electronic Power Steering (EPS) Control Unit | Behind ashtray, on center of dash. | |
| Engine Control Unit (ECU) | ||
| View of Dash | Behind right side of dash. See Figure . | |
| Engine Ctrl. Unit Location | Behind right side of dash. See Figure . | |
| Electronic Time & Alarm Ctrl. System (ETACS) Ctrl. Unit | Behind center of dash, forward of center console. See Figure . | |
| Power Seat Control Unit | Under driver's seat. | |
| Sun Roof Control Unit | Under headliner, near passenger-side sun visor. | |
| Traction Ctrl. (TCL) Ctrl. Unit | On right side of luggage compartment. See Figure . | |
