Power Window Switch Continuity Check

Fig 1: Identifying Power Window Switch Terminals

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Fig 2: Power Window Main Switch Check

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Fig 3: Identifying Power Window Sub Switch Terminals

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

POWER WINDOW SUB SWITCH CHECK

SWITCH POSITION	TESTER CONNECTION	SPECIFIED CONDITION
UP	5 - 7, 6 - 8	Less than 2 ohm
OFF	4 - 7, 6 - 8	Less than 2 ohm
DOWN	4 - 7, 5 - 6	Less than 2 ohm
