General Description
›
Shift Pattern Control
›
< 2.4L Engine > Downshift Pattern
< 2.4L Engine > Downshift Pattern
Fig 1: Shift Pattern Control - 2.4L Engine Downshift Pattern
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
