Interior Light

WARNING: This page is about a different variant/trim than selected.

The ECU related to the interior light function types and various control functions are as follows, see Fig 1.

Fig 1: Identifying Interior Light Functions & Control-ECU's

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Fig 2: Interior Light Circuit Diagram

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
