< 2.4L Engine> Downshift Pattern

WARNING: This page is about a different car, the 2004 Mitsubishi Eclipse. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Shift Pattern Control - (2.4L Engine) Downshift Pattern
G03278039Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
