Transfer Case Adapter Disassembly And Assembly: Notes

Fig 1: Disassembly And Assembly Of Transfer Case Adapter

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tools:

• MB990929: Installer Adapter
• MB990938: Handle
