General Description
›
Electronically-Controlled System
›
Shift Pattern Control
›
< 3.0L Engine (Vehicles With Variable Induction System) > Downshift Pattern
< 3.0L Engine (Vehicles With Variable Induction System) > Downshift Pattern
Fig 1: Identifying Vehicles With Variable Induction System, Downshift Pattern (3.0L Engine)
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
