Power Seat Switch Continuity Check

Fig 1: Identifying Power Seat Switch Connector Terminals

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Fig 2: Switch Position And Specified Condition Chart

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
