Disassembly And Assembly: Notes

CAUTION:

Be careful not to damage the ABS rotor, which is attached to the EBJ outer race during disassembly and reassembly.
Never disassemble the EBJ assembly except when replacing the EBJ boot.

Fig 1: Removing EBJ Boot
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

NOTE: For EBJ boot removal and installation, refer to EBJ BOOT (RESIN BOOT) REPLACEMENT .
