Disassembly And Assembly: Notes

CAUTION:
  • Be careful not to damage the ABS rotor, which is attached to the EBJ outer race during disassembly and reassembly.
  • Never disassemble the EBJ assembly except when replacing the EBJ boot.
    Fig 1: Disassembling/Assembling Of Rear Axle
    G04297098Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
