DTC B2212: Occupant Classification Module Internal: Notes

Fig 1: Checking Occupant Classification Module Internal

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

For a complete wiring diagram, refer to SYSTEM WIRING DIAGRAMS .

• When Monitored:

  While the IGN status is RUN or signal not available, while the CAN bus system voltage is between 10 and 16 volts, and during the OCS Verification Test  .

• Set Condition:

  This DTC will set if the module detects an internal failure  .

Possible Causes

OCCUPANT CLASSIFICATION MODULE
