When The Abs Fluid Pressure Is Holding: Notes

Fig 1: Active Skid Control System Operation - When ABS Fluid Pressure Is Holding

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

The system closes the inlet solenoid valve and the outlet solenoid valve to hold the brake fluid pressure in the wheel cylinders.
