Removal And Installation: Notes
Pre-removal and Post-installation Operation
- Removal and Installation of Front Pillar Trim, Upper center Pillar Trim, Rear Pillar Trim (Refer to TRIMS ).
- Removal and Installation of Rear Seatbelt Outer Assembly (RH or LH) (Refer to REAR SEAT BELT ).
- Removal and Installation of Dome Light Assembly (Refer to DOME LIGHT ).
- Removal and Installation of Passenger's Air Bag Cut OFF Indicator Light Assembly (Refer to PASSENGER'S AIR BAG ON/OFF INDICATOR LIGHT ).
