Removal And Installation: Notes

CAUTION:

• When removing or installing the camshaft position sensor or crankshaft position sensor, be careful not to apply impact to the sensor.
• Do not reuse the camshaft position sensor or crankshaft position sensor that has been dropped.

Fig 1: Water Hose And Pipe Components With Torque Specifications

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
