Pre-removal and Post-installation Operation
- Front under cover panel and front extension under cover panel Removal and Installation (Refer to UNDER COVER
).
- Engine coolant Draining and Refilling (Refer to ENGINE COOLANT CHANGE
).
- Intake duct and air cleaner assembly Removal and Installation (Refer to AIR CLEANER
).
- Headlight support upper panel cover Removal and Installation (Refer to RADIATOR GRILLE
)
|
