Removal And Installation: Notes

Fig 1: Removing/Installing Balancer Chain Components Location With Torque Specifications

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

			Removal steps
	>>F<<	1.	Peak torque limiter
<<A>>	>>E<<	2.	Flywheel bolt
	>>E<<	3.	Flywheel
	>>D<<	4.	Crankshaft rear oil seal
<<B>>	>>C<<	5.	Balancer chain tensioner
		6.	Balancer tensioner lever
		7.	Balancer chain guide
<<B>>	>>B<<	8.	Balancer shaft and oil pump module
<<B>>	>>B<<	9.	Balancer chain
<<B>>	>>B<<	10.	Crankshaft sprocket
		11.	Key
		12.	Cover
<<C>>	>>A<<	13.	Ladder frame

Required Special Tools :
