Component Location

The following illustrations are provided to assist in locating components for which removal and installation procedures are not provided. See Fig 1 .

Fig 1: Locating Engine Control System Components (1.6L)

Courtesy of AMERICAN HONDA MOTOR CO., INC.

Fig 2: Locating Engine Control System Components (2.0L)

Courtesy of AMERICAN HONDA MOTOR CO., INC.
